EATV-5

SKU: HT-935566

Lead Time

5-15 days

Shipping

Sea freight, Air freight, Express

Payment

T/T, L/C

Sample

Available

Product details

Engine	500W 36V electric motor
Optional	800W 36V electric motor
Battery	3x12V 12Ah lead acid battery
Optional	36V 13Ah lithium battery
Charger	43.2V-1.5Ah for 36V lead acid battery
Optional	42.0V-2.0Ah for 36V lithium batter
Transmission	Chain drive, with reverse gear
Final Drive	9T/72T, 25H# chain
Tires	Front 4.10-6, rear 13.00x5.0-6
Optional	Front & Rear 3.00-4
Brake System	Front 2 disc brake and rear 1 disc brake
Suspension	Front double mechanical damper, Rear mono shock absorber
Range Per Full Charge	18km
Max Speed	25km/h
Max Load Capacity	60kgs
Wheelbase	690mm
Seat Height	450mm
Min Ground Clearance	55mm
Dry Weight	47kgs-36V with lead acid battery
Dry Weight	39kgs-36V with lithium battery
Carton Size	1020x630x430mm
QTY/Container	100pcs/20FT, 245pcs/40HQ
