1 ton Mini excavator

SKU: HT-868498

Lead Time

5-15 days

Shipping

Sea freight, Air freight, Express

Payment

T/T, L/C

Sample

Available

Product details

Product overview

The Mini Excavator delivers power and performance in a compact size to help you work in a wide range of applications.1. Engine: KOOP engine, single-cylinder air cooled, 11.6HP, 8.5KW .
2. Hydraulic pump (gear pump) is easy to maintain, long life.
3. Strong lift and dig performance helps you get the job done faster. The retractable undercarriage lets you access and work inthe tightest areas. Dig-to-blade and dozer float features allow for easy clean up.
4. Multiple valves under the operating handle,The benefit of less effort and improved control is in your hands! 5. Rubber track no damage to cement, tile floor .

6. Diesel level gauge: Check engine oil when it is not easy to start.

Products Description

Vehicle weight	900kg	Maximum ground mining radius	2400mm
Standard shovel capacity	0.025-0.045m³	Swing(optinal)	75° left / 45° right
Working device form	Backhoe	Pumps	Gear pump
Rated power	8.6kw	System relief pressure-Standard	16.5MPa
Wheelbase	770mm	track width	180mm
Caterpillar chief	1090mm	Minimum radius of revolution	1190mm
Platform clearance	380mm	Maximum lift height of earth shovel	325mm
Platform end radius of gyration	733mm	Maximum digging depth of earth shovel	175mm
Emgine Model	KP-192F	Horsepower (net)	8.6kw @ 3600rpm
Cooling	water-cooling	Fuel injection	direct

Product Details

More Model

Model	NT-E08	NT-E10	NT-E13	NT-E15
Operating Weight	720kg	900kg	1150kg	1200kg
Bucket	0.02m³	0.025m³	0.026m³	0.028m³
Digging depth	1200mm	1320mm	1804mm	1810mm
Machine Width	720mm	940mm	960mm	980mm

Model	NT-E17	NT-E20	NT-E30	NT-E60
Operating Weight	1500kg	2000kg	2200kg	6010kg
Bucket	0.04m³	0.06m³	0.08m³	0.2m³
Digging depth	2000mm	2050mm	2150mm	2460mm
Machine Width	1000mm	1050mm	1200mm	1920mm
