Three-phase mid-mounted motor
SKU: HT-232604
Lead Time
5-15 days
Shipping
Sea freight, Air freight, Express
Payment
T/T, L/C
Sample
Available
Product details
Product overview
|
型号 Model |
3810型 Type 3810 |
3912型 Type 3912 |
||
|
颜色 Color |
银色 Silver |
|||
|
外观尺寸 Dimension |
(mm) |
L |
300 |
|
|
|
|
W |
140 |
|
|
|
|
H |
60 |
|
|
控制类型 Control type |
外环为转矩闭环控制 The outer loop is torque closed loop control |
|||
|
额定电压 Rated voltage |
（V） |
60 |
72 |
|
|
工作电压 Applicable voltage |
（V） |
36~80 |
||
|
峰值电流 Peak current |
（A） |
90A |
||
|
匹配电机 Matching motor |
（W） |
1000-2000 |
||
|
峰值功率 Peak power |
（W） |
5760 |
6480 |
|
|
控制器质量 Controller weight |
（kg） |
2.5 |
||
|
传感器类型 Sensor type |
霍尔传感器 Hall sensor |
|||
|
冷却方式 Cooling method |
自然风冷 Air cooling |
|||
|
环境温度 Environment temperature |
（℃） |
-30~50 |
||
|
过温保护 Overtemperature protection |
（℃） |
90 |
||
|
防护等级 Protection level |
IP55 |
|||
|
功能特点 Functional Features |
软启动、防溜坡、陡坡缓降、辅助制动、低电平刹车、三档调速，可定制一线通和CAN通讯协议。 Soft start, climbing to prevent the vehicle from slipping backward, going down the steep slope slowly in low mode,auxiliary braking, low level braking, three speed regulation, can match the one-line communication protocol and CAN communication protocol. |
|||
