Taper bush 1615 bore 38mm taper lock for taper pulley and sprockets

This taper lock bushing is a high quality, durable, and dependable product that has been precisely manufactured to out-last and out-perform the competition. taper lock bushings are used in a wide range of applications including; belt pulleys, sprockets, drum pulleys, drive pulleys, tail pulleys, sheaves, and gears, which are items that we also offer!

Installation

1. clean all oil, dirt, and paint from shaft, bushing bore, outside of bushing and component (sprocket, sheave, etc...) bore.

2. Insert bushing into component. Match the hole pattern, not the thread holes (each hole will be threaded on one side only).

3. Thread set or cap screws into those half threaded holes indicated by the  on the below diagram. mount assembly on shaft.

4. Alternately torque set or cap screws* to recommended torque setting in the chart below.

5. Fill all unoccupied holes with grease.

Removal

1. Remove all set or cap screws.

2. Insert set or cap screws in holes indicated by  on the digram above.

3. To re-install, complete all five (5) installation instructions.
