Indoor AC Load Switch FLN-12

SKU: HT-710409

Lead Time

5-15 days

Shipping

Sea freight, Air freight, Express

Payment

T/T, L/C

Sample

Available

Product details

Product overview

Environmental Conditions of Use

● Altitude not more than 2000m and seismic rift not more than 8 degrees.

● The surrounding air temperature is less than +50℃, not less than -40℃, the relative temperature is not more than 95% on daily average and not more than 90% on monthly average.

● The installation site with frequent and severe vibration, water vapor, gas, chemical corrosive deposits, salt spray, dust and dirt, and the installation site with fire and explosion hazards are not applicable.

● Rated SF6 gas pressure 0.04MPa, SF6 gas meets the requirements of GB/T 12022-2014 "Industrial Sulfur Hexafluoride".

Main Technical Parameters

Content	Unit	Parameter
Rated voltage	kV	12
Rated frequency	Hz	50
Rated current	A	630
Rated short time withstand current	kA	20/25
Rated peak withstand current	kA	50
Rated short-circuit duration	s	4
Rated short-circuit closing current	kA	50
Theoretical operation	Times	10000
Main circuit resistance	μΩ	≤35
