| Manufacturer |
-- |
-- |
HYDER |
HYDER |
| Model |
-- |
-- |
FG25 |
FG30 |
| Load capacity |
-- |
kg |
2500 |
3000 |
| Load center |
-- |
mm |
500 |
500 |
| Power unit |
-- |
-- |
gasoline + LPG |
gasoline + LPG |
| Operator type |
-- |
-- |
Driver / Seat |
Driver / Seat |
| Tire type |
Front / Rear |
-- |
pneumatic |
pneumatic |
| Wheel |
Front / Rear |
-- |
2 / 2 |
2 / 2 |
| Lifting height |
-- |
mm |
3000 |
3000 |
| Free lift |
-- |
mm |
135 |
145 |
| Fork size |
L*W*T |
mm |
1070*100*45 |
1070*125*50 |
| Tilt range |
Mast forward/backward |
deg |
6 / 12 |
6 / 12 |
| Overall length (without fork) |
-- |
mm |
2545 |
2750 |
| Total width |
-- |
mm |
1164 |
1225 |
| Mast height (fork lowering) |
-- |
mm |
2000 |
2070 |
| Overall height fork raised |
With backrest |
mm |
4000 |
4100 |
| Height to head guard |
-- |
mm |
2070 |
2150 |
| Turning raduis (outside) |
-- |
mm |
2240 |
2515 |
| Load distance |
-- |
mm |
460 |
480 |
| Min. right angle stacking aisle |
Not add load length & clearence |
mm |
2280 |
2545 |
| Speed |
Max Travelling Full / No load |
km/h |
18 /20 |
18 /19.5 |
| Lifting Full / No load |
mm/s |
570 / 600 |
450 / 500 |
| Lowering Full / No load |
mm/s |
450 / 550 |
450 / 500 |
| Max.drawbar pull |
Power shift T/M Full / No load |
kg |
1350 / 1000 |
1696 / 1190 |
| Gradeability at 1.6km/h |
Power shift T/M Full / No load |
% |
21 / 22 |
15 / 18 |
| Truck weight |
-- |
kg |
3680 |
4280 |
| Weight distribution |
Full load Front / Rear |
kg |
5480 / 700 |
6445 / 825 |
| No load Front / Rear |
kg |
1465 / 2215 |
1720 / 2560 |
| Tires |
Number |
front / rear |
2 / 2 |
2 / 2 |
| Model |
front |
700-12-12PR |
28x9-15-12PR |
| rear |
600-9-10PR |
6.50-10-10PR |
| Wheelbase |
-- |
mm |
1600 |
1760 |
| Tread |
Front / rear |
mm |
970 / 970 |
1000 / 970 |
| Ground clearence |
At lowest point (mast) |
mm |
115 |
130 |
| Frame |
mm |
170 |
200 |
| Brake |
Service brake |
-- |
Hydraulic-foot pedal |
Hydraulic-foot pedal |
| Parking brake |
-- |
Mechanical-hand lever |
Mechanical-hand lever |
| Battery |
Voltage / Capacity |
V / AH |
12 / 100 |
12 / 100 |
| Engine |
Model |
-- |
NISSAN K21 |
NISSAN K21 |
| Rated power |
KW/rpm |
31.2 / 2250 |
31.2 / 2250 |
| Rated torque |
N·m/rmp |
144 / 1600 |
144 / 1600 |
| Number of cylinders |
-- |
4 |
4 |
| Displacement |
L |
2.065 |
2.065 |
| Fuel tank capacity |
-- |
L |
60 |
70 |
| Transmission |
Speed forward/backward |
mechanical/power shift |
mechanical/auto |
mechanical/auto |
| Operating pressure |
Hydraulic system pressure |
kg/cm² |
175 |
175 |
