Roll To Roll Sticker Label Laminating Machine , multi function heavy duty sheet to sheet lamination machine
SKU: HT-243527
Lead Time
5-15 days
Shipping
Sea freight, Air freight, Express
Payment
T/T, L/C
Sample
Available
Product details
Product overview
one machine dual usage: roll to roll lamination or sheet to sheet lamination
*Single or double sides lamination ;
*Romovable conveying belt platform, convenient for film installation and operation;
*PLC intelligent operation system,LCD touch screen ;
*Three-phase AC gearbox decelerating motor, frequency conversion speed regulation
* Belt feeding for sheet lamination ,overlap size can be setted depond on customers requests;after lamination ,automatic separated to sheet
* intelligent temperature control system,
* Anti -curl function when single side lamination ,with perforating blade and slitting blade
* 180mm diameter heavy duty mirror roller,bottom silicon roller with 100mm
Detailed Images
-
Anti-curl
PLC LCD operation system
Overlap function
Belt feeding platform
180mm diameter mirror roller
double film shafts design ,easy change
Size Information
|
Model
|
RS-420B
|
|
Laminating width
|
390mm
|
|
Laminating Speed
|
0-10m/min
|
|
Roller diameter
|
180mm
|
|
Max heating temp.
|
160 degree
|
|
Heating method
|
Infrared Lamp heating
|
|
Heating power
|
2000W
|
|
Motor Power
|
250W
|
|
G.W
|
300KG
|
|
Power supply
|
AC 110V/220V ,50HZ/60HZ
|
|
package size
|
122*80*134cm
|
